VARION® C-POWER
Combined Heat and Power.
Electrical outputs range from 5kWel up to 50kWel and thermal outputs from 11.9kWth to 100kWth
The VARION® C-POWER range of CHP units introduces a new era of heat and electrical power generation. With class leading efficiencies, a host of standard features plus supremely compact designs, all models are perfect for commercial applications. To satisfy peak periods of demand, each unit is also compatible with ELCO heat pumps, as well as the range of wall mounted and floor standing boilers. Plus, VARION C-POWER CHPs are certified for use with a 40% hydrogen blend.
VARION® C-POWER
| VARION® C-POWER | Model | S 5.0 | S 7.2 | M 11.0 | M 16.0 | M 20.0 | M 21.0 | M+ 25.0 | M+ 30.0 | L 50.0 Standard | L 50.0 High temperature | L 50.0 CV |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Rated electrical power | kWel | 5 | 7.2 | 11 | 16 | 20 | 21 | 25 | 30 | 50 | 50 | 50 |
| Rated thermal power | kWth | 11.9 | 18.1 | 25.3 | 37.8 | 45.7 | 48.1 | 54.9 | 63.1 | 85 | 80 | 100 |
| Electrical power modulation | kWel | 2.9-5.0 | 3.9-7.2 | 7.5-11.0 | 9.5-16.0 | 10.7-20.0 | 10.7-21.0 | 12.5-25.0 | 15.0-30.0 | 25.0-50.0 | 25.0-50.0 | 25.0-50.0 |
| Thermal power modulation | kWth | 9.2-11.9 | 12.7-18.1 | 20.6-25.3 | 26.4-37.8 | 29.1-45.7 | 29.1-48.1 | 34.8-54.9 | 40.9-63.1 | 52.6-85.0 | 49.5-80.0 | 60.2-100.0 |
DOWNLOAD SECTION
You can download technical documents here. You can also read brochures and case studies online here.
Documents
Search
VARION® C-POWER
Technical
Instruction manual VARION C-Power 50.0
Instruction manual VARION C-Power 9.5 12.5
Technical submissions Varion C Power 11
Technical submissions Varion C Power 16
Technical submissions Varion C Power 20
Technical submissions Varion C Power 25
Technical submissions Varion C Power 30
Technical submissions Varion C Power 5.0
Technical submissions Varion C Power 50 Calorific Value
Technical submissions Varion C Power 50 High Temperature
Technical submissions Varion C Power 50 Standard
Technical submissions Varion C Power 7.2
Technology Brochure
VARION C-Power
